Part No. |
BW
(GHz)
|
Gain
(dB)
|
S11
(dB)
|
S22
(dB)
|
NF
(dB)
|
P1dB
(dBm)
|
OIP3
(dBm)
|
Vc
(V)
|
Ic
(mA)
|
Package
(mm)
|
Application |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
ZDH1025
|
0.7-3 | 24 @ 0.9GHz 21 @ 1.5GHz 18 @ 3.0GHz |
-13 | -31 | 0.4 | 22 | 35 | 5 | 78 | SOT-89 | 無線基礎設施 |
|
ZDH1025
|
0.7-3 | 22 @ 0.9GHz 20 @ 1.5GHz 17 @ 3.0GHz |
-11 | -29 | 0.4 | 19 | 30 | 3.3 | 48 | SOT-89 | 無線基礎設施 |
|
ZDH1037
|
DC-4 | 26 @ 0.5GHz 23 @ 1.5GHz 18 @ 3.5GHz |
-14 | -12 | 0.5 | 21 | 36 | 5 | 69 | SOT-89 | 無線基礎設施 |
|
ZDH1037
|
DC-4 | 25 @ 0.5GHz 21 @ 1.5GHz 17 @ 3.5GHz |
-11 | -12 | 0.6 | 17 | 30 | 3.3 | 34 | SOT-89 | 無線基礎設施 |
|
ZDH3038
|
DC-4 | 23 @ 0.5GHz 21 @ 1.5GHz 19 @ 3.5GHz |
-13 | -24 | 0.8 | 21 | 35 | 5 | 100 | SOT-89 | 無線基礎設施 |
|
ZDH3038
|
DC-4 | 22 @ 0.5GHz 20 @ 1.5GHz 18 @ 3.5GHz |
-12 | -31 | 0.8 | 17 | 29 | 3.3 | 52 | SOT-89 | 無線基礎設施 |
|
ZDH3153
|
1-6 | 22 @ 1.0GHz 16 @ 3.0GHz 10 @ 6.0GHz |
-16 | -12 | 0.6 | 22 | 31 | 5 | 68 | SOT-89 | 無線基礎設施 |
|
ZDH3153
|
1-6 | 21 @ 1.0GHz 16 @ 3.0GHz 10 @ 6.0GHz |
-18 | -13 | 0.5 | 19 | 28 | 3.3 | 39 | SOT-89 | 無線基礎設施 |
|
ZDH3157
|
0.9-3 | 21 @ 0.9GHz 16 @ 1.5GHz 11 @ 3.0GHz |
-15 | -17 | 0.5 | 23 | 40 | 5 | 66 | SOT-89 | 無線基礎設施 |
|
ZDH3157
|
0.9-3 | 20 @ 0.9GHz 15 @ 1.5GHz 11 @ 3.0GHz |
-13 | --16 | 0.4 | 20 | 33 | 3.3 | 33 | SOT-89 | 無線基礎設施 |
|
ZDH3043
|
0.1-5 | 27 @ 0.5GHz 20 @ 1.5GHz 16 @ 3.5GHz |
-17 | -11 | 0.8 | 21 | 32 | 5 | 55 | SOT-343 | 無線基礎設施 |
|
ZDH3043
|
0.1-5 | 25 @ 0.5GHz 20 @ 1.5GHz 15 @ 3.5GHz |
-16 | -13 | 0.7 | 17 | 28 | 3.3 | 33 | SOT-343 | 無線基礎設施 |
|
ZDH3143
|
0.1-3.5 | 24 @ 0.5GHz 14 @ 1.5GHz 9 @ 3.0GHz |
-31 | -15 | 0.6 | 13 | 31 | 5 | 36 | SOT-343 | 無線基礎設施 |
|
ZDH3143
|
0.1-3.5 | 20 @ 0.5GHz 13 @ 1.5GHz 8 @ 3.5GHz |
-24 | -16 | 0.8 | 17 | 22 | 3.3 | 14 | SOT-343 | 無線基礎設施 |
|
ZDH9043
|
0.2-2.2 | 23 @ 0.2GHz 23 @ 1.5GHz 17 @ 2.2GHz |
-19 | -15 | 0.8 | 17 | 31 | 5 | 16 | SOT-343 | 無線基礎設施 |
|
ZDH9043
|
0.2-2.2 | 21 @ 0.2GHz 22 @ 1.5GHz 15 @ 2.2GHz |
-15 | -11 | 0.9 | 14 | 23 | 3 | 9 | SOT-343 | 無線基礎設施 |
|
ZDH9143
|
DC-4 | 22 @ 0.5GHz 15 @ 1.5GHz 11 @ 3.5GHz |
-21 | -20 | 0.9 | 17 | 32 | 5 | 46 | SOT-343 | 無線基礎設施 |
|
ZDH9143
|
DC-4 | 21 @ 0.5GHz 15 @ 1.5GHz 11 @ 3.5GHz |
-20 | -14 | 0.8 | 18 | 31 | 3 | 21 | SOT-343 | 無線基礎設施 |
|
ZDH3025
|
0.1-3 | 27 @ 0.1GHz 20 @ 1.5GHz 14 @ 3.0GHz |
-14 | -22 | 0.6 | 21 | 34 | 5 | 59 | SOT-363 | 無線基礎設施 |
|
ZDH3025
|
0.1-3 | 27 @ 0.5GHz 20 @ 1.5GHz 15 @ 3.0GHz |
-13 | -25 | 0.7 | 18 | 30 | 3.3 | 36 | SOT-363 | 無線基礎設施 |
|
ZDH3063
|
0.1-4 | 23 @ 0.5GHz 19 @ 1.5GHz 11 @ 3.5GHz |
-20 | -22 | 0.9 | 19 | 28 | 3.3 | 30 | SOT-363 | 無線基礎設施 |
|
ZDH9022
|
0.2-2.2 | 20 @ 0.2GHz 21 @ 1.5GHz |
-30 | -14 | 0.8 | 8 | 26 | 3 | 12 | SOT-363 | 無線基礎設施、北斗 |
|
ZDH9023
|
0.2-2.2 | 21 @ 0.5GHz 24 @ 1.5GHz |
-20 | -16 | 0.9 | 15 | 27 | 5 | 18 | SOT-363 | 無線基礎設施、北斗 |
|
ZDH9023
|
0.2-2.2 | 22 @ 0.5GHz 23 @ 1.5GHz |
-19 | -13 | 0.8 | 9 | 26 | 3 | 10 | SOT-363 | 無線基礎設施、北斗 |
|
ZDH9063
|
0.2-3.7 | 23 @ 0.2GHz 21 @ 1.5GHz 21 @ 3.5GHz |
-15 | -16 | 0.8 | 16 | 30 | 5 | 33 | SOT-363 | 無線基礎設施、物聯網 |
|
ZDH9063
|
0.2-3.7 | 22 @ 0.2GHz 20 @ 1.5GHz 23 @ 3.5GHz |
-14 | -13 | 0.8 | 16 | 24 | 3.3 | 19 | SOT-363 | 無線基礎設施、物聯網 |
|
ZDH9163
|
0.9-3 | 20 @ 0.9GHz 16 @ 1.5GHz 11 @ 3.0GHz |
-21 | -21 | 0.5 | 23 | 39 | 5 | 65 | SOT-363 | 無線基礎設施 |
|
ZDH9163
|
0.9-3 | 19 @ 0.9GHz 15 @ 1.5GHz 10 @ 3.0GHz |
-20 | -22 | 0.4 | 20 | 32 | 3.3 | 31 | SOT-363 | 無線基礎設施 |
|
ZDH9263
|
DC-4 | 22 @ 0.1GHz 16 @ 1.5GHz 11 @ 3.5GHz |
-17 | -13 | 1.0 | 16 | 40 | 5 | 47 | SOT-363 | 無線基礎設施 |
|
ZDH9263
|
DC-4 | 21 @ 0.1GHz 16 @ 1.5GHz 11 @ 3.5GHz |
-13 | -15 | 1.0 | 18 | 33 | 3.3 | 26 | SOT-363 | 無線基礎設施 |
|
ZDH9007
|
0.9-1.8 | 18 @ 1.2GHz 20 @ 1.5GHz |
-7 | -32 | 0.8 | 7 | 16 | 3 | 7.6 | DFN1.1x0.7-6 | 無線基礎設施 |
|
ZDH9007
|
0.9-1.8 | 18 @ 1.2GHz 20 @ 1.5GHz |
-7 | -28 | 0.8 | 4 | 14 | 1.8 | 5.6 | DFN1.1x0.7-6 | 無線基礎設施 |
|
ZDH9025
|
0.5-3 | 24 @ 0.5GHz 21 @ 1.5GHz 17 @ 3.0GHz |
-18 | -26 | 0.4 | 20 | 32 | 5 | 55 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9025
|
0.5-3 | 22 @ 0.5GHz 20 @ 1.5GHz 15 @ 3.0GHz |
-15 | -29 | 0.4 | 18 | 27 | 3.3 | 30 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9026
|
0.5-2.6 | 22 @ 0.5GHz 23 @ 1.5GHz 24 @ 2.5GHz |
-15 | -9 | 0.8 | 18 | 32 | 5 | 33 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9026
|
0.5-2.6 | 21 @ 0.5GHz 22 @ 1.5GHz 24 @ 2.5GHz |
-12 | -14 | 0.8 | 12 | 21 | 3.3 | 18 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9037
|
DC-4 | 25 @ 0.1GHz 21 @ 1.5GHz 18 @ 3.5GHz |
-16 | -18 | 0.5 | 19 | 32 | 5 | 60 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9037
|
DC-4 | 25 @ 0.1GHz 20 @ 1.5GHz 17 @ 3.5GHz |
-14 | -19 | 0.6 | 15 | 26 | 3.3 | 35 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9039
|
DC-4.5 | 23 @ 0.5GHz 21 @ 1.5GHz 18 @ 3.5GHz |
-12 | -20 | 0.8 | 21 | 41 | 5 | 90 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9039
|
DC-4.5 | 22 @ 0.5GHz 20 @ 1.5GHz 17 @ 3.5GHz |
-11 | -19 | 0.8 | 16 | 30 | 3.3 | 48 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9051
|
0.5-4 | 24 @ 0.5GHz 18 @ 1.5GHz 12 @ 3.5GHz |
-15 | -19 | 0.4 | 23 | 31 | 5 | 37 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9051
|
0.5-4 | 23 @ 0.5GHz 16 @ 1.5GHz 12 @ 3.5GHz |
-16 | -23 | 0.4 | 20 | 25 | 3.3 | 21 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9052
|
0.7-5 | 21 @ 0.7GHz 16 @ 1.5GHz 12 @ 3.5GHz |
-16 | -18 | 0.5 | 23 | 29 | 5 | 35 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9052
|
0.7-5 | 20 @ 0.7GHz 16 @ 1.5GHz 12 @ 3.5GHz |
-12 | -17 | 0.5 | 17 | 27 | 3.3 | 20 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9057
|
0.7-1.6 | 21 @ 0.7GHz 15 @ 1.5GHz |
-14 | -22 | 0.5 | 24 | 32 | 5 | 50 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9057
|
0.7-1.6 | 21 @ 0.7GHz 15 @ 1.5GHz |
-13 | -19 | 0.5 | 19 | 32 | 3.3 | 33 | DFN2x2-8 | 無線基礎設施、北斗 |
|
ZDH9092
|
0.5-5 | 25 @ 0.5GHz 21 @ 1.5GHz 21 @ 3.5GHz |
-15 | -18 | 0.6 | 21 | 37 | 5 | 66 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9092
|
0.5-5 | 24 @ 0.5GHz 20 @ 1.5GHz 20 @ 3.5GHz |
-19 | -18 | 0.6 | 18 | 31 | 3.3 | 60 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9098
|
0.5-4 | 24 @ 0.5GHz 20 @ 1.5GHz 17 @ 3.5GHz |
-28 | -18 | 0.6 | 19 | 34 | 5 | 68 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9098
|
0.5-4 | 23 @ 0.5GHz 20 @ 1.5GHz 16 @ 3.5GHz |
-28 | -18 | 0.6 | 16 | 30 | 3.3 | 45 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9151
|
0.9-1.8 | 22 @ 0.9GHz 19 @ 1.5GHz |
-14 | -13 | 0.4 | 22 | 34 | 5 | 54 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9151
|
0.9-1.8 | 22 @ 0.9GHz 19 @ 1.5GHz |
-15 | -15 | 0.5 | 19 | 33 | 3.3 | 36 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9152
|
1.5-3 | 21 @ 1.5GHz 17 @ 3.0GHz |
-16 | -16 | 0.6 | 22 | 35 | 5 | 66 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9152
|
1.5-3 | 21 @ 1.5GHz 16 @ 3.0GHz |
-16 | -17 | 0.5 | 18 | 33 | 3.3 | 49 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9153
|
2-4 | 20 @ 2.0GHz 17 @ 3.5GHz |
-20 | -11 | 0.7 | 20 | 35 | 5 | 66 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9153
|
2-4 | 19 @ 2.0GHz 17 @ 3.5GHz |
-20 | -13 | 0.6 | 18 | 29 | 3.3 | 53 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9157
|
0.9-3 | 21 @ 0.9GHz 16 @ 1.5GHz 11 @ 3.0GHz |
-19 | -19 | 0.4 | 24 | 40 | 5 | 66 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9157
|
0.9-3 | 20 @ 0.9GHz 15 @ 1.5GHz 11 @ 3.0GHz |
-18 | -17 | 0.4 | 21 | 33 | 3.3 | 33 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9251
|
0.9-1.5 | 21 @ 0.9GHz 17 @ 1.5GHz |
-25 | -21 | 0.4 | 21 | 32 | 5 | 49 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9251
|
0.9-1.5 | 20 @ 0.7GHz 17 @ 1.5GHz |
-27 | -23 | 0.5 | 17 | 28 | 3.3 | 37 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9351
|
1.5-3 | 21 @ 1.5GHz 17 @ 3.0GHz |
-18 | -20 | 0.4 | 22 | 34 | 5 | 62 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9351
|
1.5-3 | 21 @ 1.5GHz 16 @ 3.0GHz |
-17 | -22 | 0.6 | 18 | 31 | 3.3 | 46 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9437
|
DC-4.5 | 26 @ 0.1GHz 21 @ 1.5GHz 17 @ 3.5GHz |
-17 | -19 | 0.4 | 22 | 35 | 5 | 54 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9437
|
DC-4.5 | 26 @ 0.5GHz 19 @ 1.5GHz 17 @ 3.5GHz |
-16 | -21 | 0.5 | 18 | 31 | 3.3 | 42 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9451
|
2-4 | 20 @ 2.0GHz 16 @ 3.5GHz |
-13 | -21 | 0.5 | 21 | 35 | 5 | 66 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9451
|
2-4 | 20 @ 1.5GHz 16 @ 3.5GHz |
-15 | -30 | 0.5 | 18 | 30 | 3.3 | 53 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9038
|
DC-4 | 23 @ 0.5GHz 22 @ 1.5GHz 20 @ 3.5GHz |
-17 | -31 | 0.8 | 21 | 37 | 5 | 100 | QFN3x3-16 | 無線基礎設施 |
|
ZDH9038
|
DC-4 | 22 @ 0.5GHz 21 @ 1.5GHz 20 @ 3.5GHz |
-15 | -23 | 0.8 | 17 | 30 | 3.3 | 56 | QFN3x3-16 | 無線基礎設施 |
|
ZDH8190
|
1-9 | 27 @ 1.0GHz 28 @ 5.0GHz 26 @ 9.0GHz |
-14 | -14 | 0.8 | 11 | - | 5 | 70 | QFN3x3-16 | 無線基礎設施 |
|
ZDH8260
|
2-6 | 26 @ 2.0GHz 28 @ 4.0GHz 26 @ 6.0GHz |
-28 | -18 | 0.7 | 12 | 23 | 5 | 32 | QFN3x3-16 | 無線基礎設施 |
|
ZDH8480
|
4-8 | 28 @ 4.0GHz 27 @ 6.0GHz 25 @ 8.0GHz |
-18 | -26 | 0.9 | 12 | 25 | 5 | 28 | QFN3x3-16 | 無線基礎設施 |
|
ZDH9190
|
1-9 | 22 @ 1.0GHz 25 @ 5.0GHz 26 @ 9.0GHz |
-17 | -15 | 0.8 | 14 | 28 | 5 | 37 | QFN3x3-16 | 無線基礎設施 |
|
ZDE8025
|
24-30 | 18 | -11 | -12 | 1.6 | 7 | - | 5 | 20 | 2.72*1.23 | 毫米波通信 |
|
ZDE8030
|
26-36 | 15 | -10 | -11 | 1.9 | 12 | - | 5 | 40 | 2.665*1.23 | 毫米波通信 |
|
ZDE9190
|
1-9 | 25 | -17 | -15 | 0.8 | 14 | 28 | 5 | 37 | 1.95*1.395 | S-C-X波段應用 |
|
ZDE9220
|
2-20 | 18 | -15 | -17 | 2.1 | 12 | - | 5 | 45 | 3.12*1.48 | S-C-X-KU波段應用 |
|
ZDE9618
|
6-18 | 23 | -13 | -14 | 1.2 | 12 | - | 5 | 30 | 1.6*0.9 | C-X-KU波段應用 |
|
ZDH9012
|
DC-3 | 13 | 29 | 15 | 0.5 | 25 | 34 | 5 | 65 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9127
|
0.1-3 | 25 | 0.5 | 14 | 27 | 3.3 | 31 | DFN2x2-8 | DFN2x2-8 | ||
|
ZDH9268
|
DC-5 | 22 | 12 | 10 | 0.4 | 20 | 29 | 3.3 | 50 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9268
|
DC-5 | 23 | 14 | 10 | 0.4 | 24 | 35 | 5 | 110 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9127
|
0.1-3 | 27 | 18 | 10 | 0.5 | 18 | 36 | 5 | 56 | DFN2x2-8 | 無線基礎設施 |
|
ZDH9099
|
DC-4 | 15 | -14 | -17 | 1.6 | 21 | 33 | 5 | 57 | DFN2x2-8 | 無線基礎設施、北斗 |
